Description
For all the wedding videographers, drone camera operators, and multimedia journalists who have professional photo still and cinema video production needs, get ready for a new type of shooting experience with the EOS R5 C Mirrorless Cinema Camera from Canon. With a simple switch, the R5 C is a full featured still photo camera with all the settings of the R5 EOS mirrorless camera. When switched in the other direction, it becomes a full-frame 8K60 Cinema EOS camera that internally records 12-bit Cinema RAW Light footage. There's no more need to carry a second camera with you to your production when stills and video are available within a single compact design.
The R5 C enhances a number of features in comparison to its siblings the R5 and C70, including 4K120 recording, HDMI RAW output, Canon Log 3 HLG/PQ support, unlimited recording time, a timecode port, Dual Pixel CMOS AF with eye detection, an active cooling system, a high-power LP-E6NH battery, 13 reassignable buttons, and a multi-function shoe for XLR adapters. The camera also retains the reliable features of those cameras such as Wi-Fi/Bluetooth, footage compatibility with DaVinci Resolve and Canon apps, an electronic RF mount, CFexpress/SD card slots, a similar button layout, and more. The EOS R5 C is also moisture and dustproof to the same level as its cinema cousin, the EOS C70. And all this is packed into a tiny 1.7 lb body that is just asking to become your go-to drone camera.
Specifications
| Imaging | |
| Lens Mount | Canon RF |
| Lens Communication | Yes, with Autofocus Support |
| Sensor Resolution | Actual: 47.1 Megapixel Effective: 45 Megapixel (8192 x 5464) |
| Image Sensor | 36 x 24 mm (Full-Frame) CMOS |
| Image Stabilization | Digital |
| Built-In ND Filter | No |
| Internal Filter Holder | No |
| Capture Type | Stills & Video |
| Exposure Control | |
| Shutter Type |
Mechanical Focal Plane Shutter and Electronic Rolling Shutter
|
| Shutter Speed | Mechanical Shutter 1/8000 to 30 Seconds Electronic Front Curtain Shutter 1/8000 to 30 Seconds Electronic Shutter 1/8000 to 0.5 Seconds |
| Bulb/Time Mode | Bulb Mode |
| ISO Sensitivity Range |
100 to 51,200 in Manual Mode (Extended: 50 to 102,400) 100 to 12,800 in Auto Mode (Extended: 100 to 51,200) Video 100 to 51,200 (Extended: 50 to 102,400) |
| Metering Method |
Center-Weighted Average, Evaluative, Partial, Spot
|
| Exposure Modes |
Aperture Priority, Manual, Program, Shutter Priority
|
| Exposure Compensation | -3 to +3 EV (1/3, 1/2 EV Steps) |
| Metering Range | -3 to 20 EV |
| White Balance |
0 to 0K
Presets: Auto, Cloudy, Color Temperature, Custom, Daylight, Flash, Fluorescent (White), Tungsten |
| Continuous Shooting |
Mechanical Shutter
Up to 12 fps at 45 MP for up to 180 Frames (Raw) / 350 Frames (JPEG) Electronic Shutter Up to 20 fps at 45 MP for up to 83 Frames (Raw) / 170 Frames (JPEG) |
| Interval Recording | Yes |
| Self-Timer | 2/10-Second Delay |
| Video Capture | |
| Internal Recording Modes |
Cinema RAW Light/Raw 12-Bit
8192 x 4320 at 23.98/24.00/25/29.97/50/59.94 fps [1030 to 2570 Mb/s] 5952 x 3140 at 23.98/24.00/29.97/50/59.94 fps [544 to 1360 Mb/s] 2976 x 1570 at 23.98/24.00/25/29.97/50/59.94 fps [138 to 344 Mb/s] AVC-Intra/AVC-LongG/XF-AVC 4:2:2 10-Bit DCI 4K (4096 x 2160) at 23.98/24.00/25/29.97/59.94/100/120 fps [160 to 810 Mb/s] UHD 4K (3840 x 2160) at 23.98/25/29.97/50/59.94/100/120 fps [160 to 810 Mb/s] 1920 x 1080p at 23.98/25/29.97/50/59.94/120 fps [50 to 310 Mb/s] 1280 x 720 at 50/59.94 fps [8 to 12 Mb/s] AVC-LongG/MP4 4:2:2 10-Bit DCI 8K (8192 x 4320) at 23.98/24.00/25/29.97 fps [400 to 540 Mb/s] UHD 8K (7680 x 4320) at 23.98/25/29.97 fps [400 to 540 Mb/s] DCI 4K (4096 x 2160) at 23.98/24.00/25/29.97/50/59.94/100/120 fps [100 to 225 Mb/s] UHD 4K (3840 x 2160) at 23.98/25/29.97/50/59.94/120 fps [100 to 225 Mb/s] DCI 2K (2048 x 1080) at 23.98/24.00/25/29.97/50/59.94 fps [35 to 50 Mb/s] 1920 x 1080p at 23.98/25/29.97/50/59.94 fps [35 to 50 Mb/s] 1280 x 720 at 50/59.94 fps [8 to 12 Mb/s] AVC-LongG/MP4 4:2:0 8-Bit DCI 4K (4096 x 2160) at 23.98/24.00/25/29.97/50/59.94/120 fps [100 to 225 Mb/s] UHD 4K (3840 x 2160) at 23.98/24.00/25/29.97/50/59.94 fps [100 to 225 Mb/s] DCI 2K (2048 x 1080) at 23.98/24.00/25/29.97/50/59.94 fps [35 to 50 Mb/s] 1920 x 1080p at 23.98/24.00/29.97/50/59.94 fps [35 to 50 Mb/s] 1280 x 720 at 50/59.94 fps [8 to 12 Mb/s] |
| External Recording Modes | 4:2:2 10-Bit via HDMI DCI 4K (4096 x 2160) up to 59.94 fps UHD 4K (3840 x 2160) up to 59.94 fps |
| Fast-/Slow-Motion Support | Yes |
| Gamma Curve |
Canon Log 3, HDR-HLG, HDR-PQ, Rec709, Rec2020
|
| Broadcast Output | NTSC/PAL |
| IP Streaming | No |
| Still Image Capture | |
| Image Sizes | 3:2 JPEG / Raw 8192 x 5464 5088 x 3392 3:2 JPEG / Raw 8192 x 5464 5808 x 3872 4176 x 2784 2400 x 1600 4:3 JPEG / Raw 7280 x 5464 5152 x 3872 3715 x 2784 2112 x 1600 16:9 JPEG / Raw 8192 x 4608 5808 x 3264 4176 x 2344 2400 x 1344 1:1 JPEG / Raw 5456 x 5456 3872 x 3872 2784 x 2784 1600 x 1600 |
| Aspect Ratio | 1:1, 3:2, 4:3, 16:9 |
| Image File Format | C-RAW, HEIF, JPEG, Raw |
| Bit Depth | 14-Bit |
| Interface | |
| Media/Memory Card Slot | Slot 1: CFexpress Type B Slot 2: SD/SDHC/SDXC (UHS-II) |
| Video I/O | 1 x Micro-HDMI (Unspecified Signal) Output |
| Audio I/O |
1 x 1/8" / 3.5 mm TRS Stereo Mic/Line Input
1 x 1/8" / 3.5 mm TRS Stereo Headphone Output |
| Power I/O | 1 x USB-C (9VDC at 3 A) Input |
| Other I/O |
1 x USB-C (USB 3.2 / 3.1 Gen 2) (Shared with Power Input)
|
| Wireless |
Bluetooth Control
2.4 / 5 GHz Wi-Fi (802.11b/g), Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) Video Output, Control |
| Global Positioning (GPS, GLONASS, etc.) | No |
| Monitor | |
| Display Type | Free-Angle Tilting Touchscreen LCD |
| Display Size | 3.2" |
| Resolution | 2,100,000 Dot |
| Viewfinder | |
| Type | Built-In Electronic (OLED) |
| Size | 0.5" |
| Resolution | 5,790,000 Dot |
| Eye Point | 23 mm |
| Coverage | 100% |
| Magnification | Approx. 0.76x |
| Diopter Adjustment | -4 to +2 |
| Focus | |
| Focus Type | Auto and Manual Focus |
| Focus Mode |
Continuous-Servo AF, Manual Focus, Single-Servo AF
|
| Autofocus Points | Phase Detection: 1053 |
| Autofocus Sensitivity | -6 to +20 EV |
| Built-In Flash/Light | No |
| Maximum Sync Speed | 1/250 Second |
| Flash Compensation | -3 to +3 EV (1/3, 1/2 EV Steps) |
| Dedicated Flash System | eTTL |
| External Flash Connection | Shoe Mount |
| Environmental | |
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Operating Humidity | 0 to 85% |
| General | |
| Battery Type | Canon LP-E6N |
| Shoe Mount | 1 x Intelligent Hot Shoe |
| Tripod Mounting Thread | 1 x 1/4"-20 Female (Bottom) |
| Dimensions (W x H x D) | 5.6 x 4 x 4.4" / 142.2 x 101.6 x 111.8 mm |
| Weight | 1.5 lb / 680 g (Body Only) 1.7 lb / 770 g (With Battery, Recording Media) |
| Packaging Info | |
| Package Weight | 3.205 lb |
| Box Dimensions (LxWxH) | 9.5 x 7.9 x 7.9" |
