Description

AJA KUMO 6464 (KUMO6464) Compact 64x64 3G-SDI Router. The KUMO 6464 router offers an incredible 64 inputs and 64 outputs of 3G-SDI video and audio, while maintaining a slim and compact 4RU profile. KUMO 6464 has elegant and powerful web-based network control, and supports any SDI-based signal up to 3G-SDI, including HD and even 4K/UltraHD signals. Built to the same high quality standards as all AJA KUMO products, KUMO 6464 is the ideal choice for any installation where a balance of size and routing capacity are critical.

Compact Routing
The KUMO 6464 compact SDI router provides powerful signal control and supports full broadcast specifications over SDI, HD-SDI, and 3G-SDI, with quality that exceeds SMPTE specifications. The super compact 4RU size is just a 1.5 inches deep, making it a perfect fit for any broadcast, production, or postproduction environment, from mobile sports trucks and edit suites, through to corporate video installations or live theatrical A/V rigs

Features

Compact Routing
Powerful Signal Control
Broadcast Standard Reliability
Simple Installation and Configuration
Affordable

Specifications

Video Formats	(HD) 1080i 25, 29.97, 30
	(HD) 1080PsF 23.98, 24, 25, 29.97, 30
	(HD) 1080p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60
	(HD) 720p 50, 59.94, 60
	(SD) 625i 25
	(SD) 525i 29.97

Video Input Digital	3G-SDI, SMPTE-259/292/424, 8 or 10-bits
	Single Link 4:2:2 (1 x BNC per input)

Video Output Digital	3G-SDI, SMPTE-259/292/424 8 or 10-bits
	Single Link 4:2:2 (1 x BNC per input)
	Reclocker: SMPTE 259/292/424 compliant, automatic rate selection

Audio Input Digital	8-Channel, 24-bit SMPTE-259 SDI embedded audio, 48 kHz sample rate, synchronous

Audio Output Digital	8-Channel, 24-bit SMPTE-259 SDI embedded audio, 48 kHz sample rate, synchronous

Switching Modes	Quad Link
	Supports 4K/UltraHD
	Dual Link
	Multiport SDI switching for 2 or 4 sources at once

Timecode	SDI RP188 preserved from inputs to outputs

Reference Input	Analog Color Black (1V) or Composite Sync (2 or 4V)
	Looping, nonterminating

Network Interface	10/100/1000 Ethernet (RJ-45)
	Embedded web server for remote control

Machine Control	RS-422, Grass Valley Native Protocol
	9-pin D-connector pinout is as follows:

Size (w x d x h)	19.0" x 1.5" x 7" (482.6mm x 38.1mm x 178.0mm)

Weight	9.2 lbs (4.2 kg)

Power	100-240 VAC 50/60 Hz, 9-17 VDC, 12 VDC nominal, Optional redundant power supply
	35 watts, 2.9A at 12VDC

Environment	Safe Operating Temperature: 0 to 40 degrees C (32 to 104 degrees F)
	Safe Storage Temperature (Power OFF): -40 to 60 degrees C (-40 to 140 degrees F)
	Operating Relative Humidity: 10-90% noncondensing
	Operating Altitude: Less than 3,000 meters (Less than 10,000 feet)
