Description
For a wide range of high-resolution and professional options when mobile or in the studio, use the Panasonic AG-UX90 UHD 4K Camcorder for recording up to UHD 3840 x 2160 video and 8-mode gamma. The AG-UX90 features a large, 1.0-type MOS sensor that creates a dramatic bokeh with its wide-angle lens, and its focal length with 15x optical zoom ranges from 25.4 to 367.5mm. The camera's 5-axis Hybrid Image Stabilizer provides anti-shake correction for smooth movement, and the 3-ring lens design allows for precision iris/focus/zoom manual control. The shutter system functions in three modes—System, Slow, and Synchro Scan—which allow for shutter speeds from 1/60 to 1/8000 per second. The three-step variable gain switch allows for greater control over brightness and shutter.
Features
- UHD 4K Resolution, 1.0-Type MOS Sensor
- 8-Mode Gamma, MOV/MP4/AVCHD Formats
- Composite, 8-Bit 4:2:0 HDMI Video Output
- Variable Rate Recording up to 60 fps
- 25.4 to 367.5mm Lens, 15x Optical Zoom
- 5-Axis Hybrid Image Stabilizer
- 2 x SDHC/SDXC Card Slots, UHS-I Support
- Variable Gain Selector Switch
Specifications
| Sensor Resolution | Effective: 8.59 Megapixel |
| Sensor Type | 1"-Type MOS Sensor |
| Image Stabilization | Optical in Integrated Lens |
| Built-In ND Filter | No |
| Capture Type | Video Only |
| Shutter Type | Not Specified by Manufacturer |
| Shutter Speed | 1/8000 to 1/60 Second |
| Gain | 0 to 30 dB (Native) |
| Precise Scan Rate Control | Yes |
| Minimum Illumination | 1.3 Lux at 1/30 Shutter Speed |
| White Balance | 2000 to 15,000K |
| Recording Modes | MP4 4:2:0 8-Bit 3840 x 2160 at 23.98p/29.97p [100 Mb/s] 1920 x 1080 at 23.98p/29.97p/59.94p [50 to 200 Mb/s] AVCHD 4:2:0 8-Bit 1920 x 1080 at 23.98p/59.94p [21 to 25 Mb/s] 1920 x 1080 at 59.94i [17 to 21 Mb/s] 1440 x 1080 at 59.94i [5 Mb/s] 1280 x 720 at 59.94p [8 Mb/s] 720 x 480 at 59.94i [9 Mb/s] |
| Variable Frame Rates | 1080p: 2 to 60 fps 1080p: 2 to 60 fps |
| Recording Limit | Up to 3360 Minutes |
| Built-In Microphone Type | Stereo |
| Audio Recording | MP4: 2-Channel 16-Bit 48 kHz LPCM Audio AVCHD: 2-Channel 16-Bit 48 kHz LPCM Audio |
| IP Streaming | No |
| Image Sizes | 16:9 JPEG 8.3 MP (3840 x 2160) 2 MP (1920 x 1080) 0.9 MP (1280 x 720) |
| Image File Format | JPEG |
| Media/Memory Card Slot |
Dual Slot: SD/SDHC/SDXC (UHS-I) [Class 10/U1/V10 or Faster Recommended]
|
| Video I/O | 1 x RCA (Composite) Output 1 x HDMI Output |
| Audio I/O | 2 x XLR 3-Pin Mic/Line (+48 V Phantom Power) Input 1 x 1/8" / 3.5 mm TRS Stereo Headphone Output |
| Power I/O | 1 x Proprietary (7.2 to 12 VDC) Input |
| Other I/O | 1 x 2.5 mm Sub-Mini (Camera Interface) Control Input 1 x 1/8" / 3.5 mm (Camera Interface) Control Input 1 x USB-A (Camera Interface) Data Output 1 x Micro-USB (Camera Interface) Data Input/Output |
| Wireless | No |
| Global Positioning (GPS, GLONASS, etc.) | No |
| Display Size | 3.5" |
| Resolution | 1,150,000 Dot |
| Display Type | Articulating LCD |
| Type | Built-In Electronic (OLED) |
| Size | 0.24" |
| Resolution | 1,560,000 Dot |
| Focus Type | Auto and Manual Focus |
| Focus Mode | Automatic, Manual Focus |
| Operating Temperature | 0 to 40°C |
| Operating Humidity | 10 to 80% |
| Battery Type | Panasonic AG-VBR Series |
| Power Consumption | 12.2 W |
| Tripod Mounting Thread | 1/4"-20 Female |
| Accessory Mounting Thread | 1 x |
| Weight | 1.91 kg |
What's in the box
- Panasonic AG-UX90 4K/HD Professional Camcorder
- 7.28V 43Wh Battery for DVX200 (5,900mAh)
- Battery Charger for AG-VBR & Other Batteries
- AC Adapter
- Microphone Holder Kit
- Eyecup
- Lens Hood
- Input Terminal Cap
- AC Cable
- Limited 1-Year Warranty
