The Belkin Connect Thunderbolt 4 Docking Station 5-in-1 Core Hub transforms your workflow with comprehensive connectivity. Featuring four 40 Gb/s Thunderbolt 4 ports—one delivering up to 96W of power to your host device and three providing 15W each for accessories—alongside a dedicated 10 Gb/s USB-A 3.2 Gen 2 port for peripherals. Support for dual 4K/60 Hz displays or a single 8K/30 Hz display ensures exceptional visual performance, while daisy-chaining capabilities accommodate up to six Thunderbolt devices. The integrated status light provides operational clarity, and the included 150W power supply with Thunderbolt 4 cable delivers everything needed for seamless integration into your professional setup.
Features
- Four Total Thunderbolt 4 Ports
- 1 x Thunderbolt 4 Host Port (96W)
- 3 x Thunderbolt 4 Accessory Ports (15W)
- 1 x USB-A 3.2 Gen 2 Port
- Data Transfers up to 40 Gb/s
- Supports Dual 4K/60 Hz Displays
- Supports One 8K/30 Hz Display
- Daisy-Chain up to 6 Devices
- Includes Thunderbolt 4 Cable
- Includes 150W Power Supply
Specifications
| USB I/O |
3x USB-C (Thunderbolt 4) / Supports Video Alt Mode and 15 W per Port |
|
1x USB-A 3.1/3.2 Gen 2 |
| Video I/O |
-
|
| Max Resolution |
2 Displays Supported: |
|
7680 x 4320 at 30 Hz (Single) |
|
3840 x 2160 at 60 Hz (Dual) |
| Audio I/O |
-
|
| Network I/O |
-
|
| Host Connection |
USB-C (Thunderbolt 4) Supporting USB Power Delivery up to 96 W via Detachable Cable |
| Power Source |
Included AC Adapter with Barrel Connector ( W) |
| Media Card Reader |
-
|
| Wireless Charging |
-
|
| OS Compatibility |
Computer: macOS |
|
Mobile: iPadOS Only |
| Operating Conditions |
0 to 40°C at 10 to 90% Humidity |
| Storage Conditions |
-30 to 70°C at 40 to 85% Humidity |
| Lock Slot |
No |
| Cable Length |
1.8 m |
| Weight |
- |
What's in the box
- Belkin 5-in-1 Thunderbolt 4 Core Hub
- Thunderbolt 4 Cable (6')
- 150W Power Supply
- Limited 2-Year Manufacturer Warrant
