Description
The Blackmagic Design Pocket Cinema Camera 6K Pro tops it off with additional pro features such as built-in 2, 4 and 6 stop ND filters, an adjustable 5" tilt HDR LCD with a bright 1500 nits that's ideal when operating in bright sunlight, an accurate timecode clock, 2 mini XLR audio inputs, a larger NP-F570 battery and the latest Generation 5 Colour Science.
The 6K Pro Cinema Camera from Blackmagic still packs the large 6144 x 3456 Super 35mm Sensor; to capture high-quality cinematic video footage and shallower depths of field. Recording has enhanced in so many ways where you can now record 6K; with frame rates of up to 50 fps at a striking 6144 x 3456 16:9 native resolution; a dual native 400 & 3200 ISO to 25 600 ensuring beautiful low noise images in all kinds of lighting conditions.
The lightweight Blackmagic Design Pocket Cinema Camera 6K Pro features an EF lens mount; letting you take advantage of larger EF photographic lenses to create astonishing cinematic images, making it the ideal camera for television programming; feature filming and documentaries. The high-end 6K Pro camera combines the sensor with the latest Blackmagic Generation 5 Colour Science for stunning skin tones and faithful colour reproduction; and to achieve enhanced imaging technology that features in most expensive digital film cameras. The EF mount lens also allows you to still adjust focus and iris from the buttons on the camera or the touch screen.
Other powerful features and specifications includes 13 stops of dynamic range; an impressive bright 5" tilting HDR capacitive touchscreen LCD; as well as a 1920 x 1080 monitor output; professional audio support consisting dual mini XLR inputs with phantom +48V power as well as 4 built-in mics; 3D LUT application for both monitoring and recording; image quality of up to 21.2MP; built-in CFast and SD UHS-II card recorders; and a USB-C expansion port; a built-in timecode generator for faster Multi Camera Shoots in Perfect Sync. You can even control your Blackmagic Design Pocket Cinema Camera 6K Pro via a Bluetooth connection; and even trigger all cameras to record at the same time.
Specifications
| Lens Mount | Canon EF |
| Lens Communication |
Yes, with Autofocus Support
|
| Sensor Resolution |
Effective: 21.2 Megapixel (6144 x 3456)
|
| Sensor Type |
23.1 x 12.99 mm (Super35) CMOS
|
| Image Stabilization | None |
| Built-In ND Filter |
Mechanical Filter Wheel with Clear, 2 Stop (1/4), 4 Stop (1/16), 6 Stop (1/64) ND Filters
|
| Internal Filter Holder | No |
| Capture Type | Stills & Video |
|
Exposure Control
|
|
| Shutter Type |
Electronic Rolling Shutter
|
| ISO Sensitivity | 100 to 25,600 |
| Shutter Angle | 5 to 360° |
| Advertised Dynamic Range | 13 Stops |
| Video Capture | |
| Internal Recording Modes |
ProRes 422/ProRes 422 HQ/ProRes 422 Proxy/ProRes 422LT
DCI 4K (4096 x 2160) up to 60.00 fps UHD 4K (3840 x 2160) up to 60.00 fps 1920 x 1080p up to fps Blackmagic RAW 6144 x 3456 at 23.98/24.00/25/29.97/50 fps [49 to 483 Mb/s] 6144 x 2560 at 23.98/24.00/25/29.97/50/59.94 fps [37 to 359 Mb/s] 5744 x 3024 at 23.98/24.00/25/29.97/50/59.94 fps [40 to 395 Mb/s] 4096 x 2160 at 23.98/24.00/25/29.97 fps [28 to 163 Mb/s] 3728 x 3104 at 23.98/24.00/25/29.97 fps [36 to 265 Mb/s] 2868 x 1512 at 23.98/24.00/25/29.97 fps [14 to 101 Mb/s] |
| External Recording Modes |
4:2:2 10-Bit via HDMI
1920 x 1080p Raw via USB 6144 x 3456 at 23.98/24.00/25/29.97/50 fps 6144 x 2560 at 23.98/24.00/25/29.97/50/59.94 fps 5744 x 3024 at 23.98/24.00/25/29.97/50/59.94 fps |
| Sensor Crop While Recording |
6K (6144 x 2560) in 2.4:1 When Recording in Raw
5744 x 3024 When Recording in Raw 4K (4096 x 2160) When Recording in Raw 3728 x 3104 When Recording in Raw 2868 x 1512 When Recording in Raw |
| Fast-/Slow-Motion Support | Yes |
| Built-In Microphone Type | Stereo |
| IP Streaming | Yes |
|
Still Image Capture
|
|
| Image File Format | DNG |
| Interface | |
| Media/Memory Card Slot |
Slot 1: SD/SDHC/SDXC (UHS-II)
Slot 2: CFast |
| Video I/O |
1 x HDMI Output
|
| Audio I/O |
2 x Mini XLR Mic/Line (+48 V Phantom Power) Input
1 x 1/8" / 3.5 mm TRS Stereo Mic/Line Input 1 x 1/8" / 3.5 mm TRS Stereo Headphone Output |
| Power I/O |
1 x Weipu SF610/S2 (12 to 20 VDC) Input
|
| Other I/O |
1 x USB-C (USB 3.2 / 3.1 Gen 1) Control/Video Output
1 x 1/8" / 3.5 mm (Timecode) Input (Shared with Mic/Line Input) |
| Wireless |
Bluetooth Control
|
| Global Positioning (GPS, GLONASS, etc.) | None |
| Monitor | |
| Size | 5" |
| Resolution | 1920 x 1080 |
| Display Type |
Tilting Touchscreen LCD
|
| Type |
Optional, Not Included
|
| Focus | |
| Focus Type |
Auto and Manual Focus
|
| Environmental | |
| Operating Temperature |
32 to 104°F / 0 to 40°C
|
| Storage Temperature |
-4 to 113°F / -20 to 45°C
|
| Operating Humidity | 0 to 90% |
| General | |
| Battery Type | Sony L-Series |
| Tripod Mounting Thread |
2 x 1/4"-20 Female
|
| Accessory Mount |
1 x 1/4"-20 Female
|
| Material of Construction | Carbon Fiber |
| Dimensions (W x H x D) |
7.08 x 4.41 x 4.84" / 179.83 x 112.01 x 122.94 mm
|
| Weight |
2.73 lb / 1.24 kg
|
