Description
Unlock the next level of filmmaking with the Blackmagic Pocket Cinema Camera 4K. Its 4/3 image sensor and 4096 x 2160 resolution combine with a MFT lens mount to produce stunning, Hollywood-quality digital images in a compact design. Create beautiful, dynamic footage with superior wide dynamic range and experience the premium quality of digital filmmaking.
Capture cinema quality films with the Blackmagic Pocket Cinema Camera 4K. This body-only model comes with a multifunction grip, featuring fingertip ISO, WB and shutter controls. An ergonomically designed scroll wheel ensures precise iris adjustments, while additional buttons offer pro-level functions such as focus zoom, false color and high frame rate. Perfect for capturing those special moments.
Experience stunning low-noise images, even in low light, with the Blackmagic Pocket Cinema Camera 4K. Featuring a high resolution, cinematic digital film sensor, powerful 13-stop dynamic range, dual native ISO up to 25,600, and 6K sensor option with shallow depth-of-field and anamorphic lenses, the Pocket 4K captures crisp visuals in any lighting condition. Enjoy beautiful images straight out of the camera, with Blackmagic’s advanced color science.
Features
- 4/3"-Sized HDR Sensor
- DCI 4K60, 2.8K80 Raw in 4:3 Anamorphic
- Dual Native 400/3200 ISO / up to 25,600
- Up to 2.6K 120 Raw for Super16 Lenses
- 5" Touchscreen Display
- Active Micro Four Thirds Lens Mount
- CFast 2.0 & SD/UHS-II Card Slots
- External Recording via USB Type-C
- 13-Stop Dynamic Range, 3D LUT Support
- Includes DaVinci Resolve Studio License
Specifications
| Effective Sensor Size |
18.96mm x 10mm (Four Thirds)
|
| Lens Mount |
Active MFT mount.
|
| Shooting Resolutions |
4096 x 2160 (4K DCI), 3840 x 2160 (Ultra HD), 1920 x 1080 (HD).
|
| Dynamic Range | 13 Stops. |
| Frame Rates |
Maximum sensor frame rate dependent on resolution and codec selected. Project frame rates of 23.98, 24, 25, 29.97, 30, 50, 59.94 and 60 fps supported. Off-speed frame rates up to 60 fps in 4K DCI, 120 fps in HD windowed.
|
| Lens Control |
Iris, focus and zoom on supported lenses.
|
| Focus |
Focus button turns on peaking, auto focus available using compatible lenses.
|
| Iris Control |
Iris wheel and touchscreen slider for manual iris adjustment on electronically controllable lenses, iris button for instant auto iris settings on compatible lenses so no pixel is clipped in film mode. Scene average auto exposure in video mode.
|
| Screen Dimensions | 5” 1920 x 1080. |
| Screen Type |
LCD capacitive touchscreen.
|
| Controls |
Touchscreen menus on 5 inch screen. 1 x Power Switch, 1 x Record Button, 1 x Stills Button, 1 x Scroll Wheel with push integrated into handgrip, 1 x ISO Button, 1 x White Balance, 1 x Shutter Button, 3 x software configurable Fn buttons, 1 x High Frame Rate (HFR) Button, 1 x Zoom Button, 1 x Menu Button, 1 x Play Button, 1 x Focus Button and 1 x IRIS Button.
|
|
Connections
|
|
| Total Video Inputs | None. |
| Total Video Outputs |
1 x HDMI Type A
|
| Analog Audio Inputs |
1 x mini XLR analog switchable between mic with phantom power support and line level (up to +14dBu).
|
|
1 x 3.5mm Stereo Input. Can also be used for Timecode input.
|
|
| Analog Audio Outputs |
1 x 3.5mm headphone jack.
|
| Computer Interface |
USB Type-C for external drive recording, software updates and media download.
|
| Audio | |
| Microphone |
Integrated stereo microphone.
|
| Built in Speaker |
1 x mono speaker.
|
| Standards | |
| SD Video Standards | None. |
| HD Video Standards |
1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60.
|
| Ultra HD Video Standards |
2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60.
|
| 4K DCI Standards |
4KDCIp23.98, 4KDCIp24, 4KDCIp25, 4KDCIp29.97, 4KDCIp30, 4KDCIp50, 4KDCIp59.94, 4KDCIp60.
|
| Media | |
| Media |
Can format cards to ExFAT for Windows and Mac or HFS+ for Mac (file systems).
|
|
Storage Features
|
|
| Storage Type |
-1 x CFast 2.0. - 1 x SD UHS-II card. |
| Storage Rates |
~4096 x 2160 - CinemaDNG RAW - 270 MB/s, - CinemaDNG RAW 3:1 - 128 MB/s,
- CinemaDNG RAW 4:1 - 96 MB/s,
~3840 x 2160
- Apple ProRes 422 HQ - 110 MB/s,
- Apple ProRes 422 - 73.6 MB/s,
- Apple ProRes 422 LT - 51 MB/s,
- Apple ProRes Proxy - 22.4 MB/s
,
- Storage rates based on 30 frames per second.
|
| Software | |
| Software Included |
- Pocket Cinema Camera 4K Operating System.
- DaVinci Resolve Studio on SD Card.
- Blackmagic Camera Setup.
|
|
|
|
| Operating Systems |
- macOS 10.12 Sierra
- macOS 10.13 High Sierra or later.
- Windows 8.1 or Windows 10.
|
|
|
|
| Power Supply |
1 x External 12V power supply.
|
| External Power Input |
1 x 2-pin locking connector.
|
| Battery Type | Canon LP-E6. |
| Battery Life |
Approximately 60 minutes.
|
| Power | 12V-20V |
|
Environmental Specifications
|
|
| Operating Temperature |
0°to 40°C (32° to 104°F)
|
| Storage Temperature |
-20°to 45°C (-4° to 113°F)
|
| Relative Humidity |
0% to 90% non-condensing
|
| What's Included |
- Blackmagic Pocket Cinema Camera 4K
- Lens turret dust cap.
- 30W power supply with locking connector and international adapters.
- LP-E6 battery.
- SD card with software and manual.
- Welcome card.
- DaVinci Resolve Studio with activation key.
|
|
|
|
| Warranty | |
| Product Warranty |
12 Month Limited Manufacturer's Warranty.
|
What's in the box
- Blackmagic Design Pocket Cinema Camera 4K
- DaVinci Resolve Studio Activation Key
- Canon LP-E6 Type Battery
- 30W Power Supply with International Adapters
- Dust Cap
- Limited 1-Year Manufacturer Warranty
