Blackmagic URSA Mini Pro 4.6K G2 EF (body only). Side Handle & LANC Cable not included
Description
Firmware Update 6.9.2: For the latest firmware update.
URSA Mini Pro 4.6K G2, is a professional digital film camera that combines incredible 4.6K image quality with the features and controls of a traditional broadcast camera. The second generation URSA Mini Pro features fully redesigned electronics and a new Super 35mm 4.6K HDR image sensor that combine to give you much higher frame rate shooting. You also get built in ND filters, an interchangeable lens mount, Blackmagic RAW support, and both dual CFast and SD UHS-II card recorders for capturing images at up to 300 frames per second. There’s even a USB-C expansion port that lets you record directly to flash drives or SSD disks for even longer recording times....
Features
- Digital film camera with 15 stops of dynamic range
- Super 35mm 4.6K sensor with Blackmagic Design Generation 4 Colour Science
- Supports project frame rates up to 60 fps and off-speed slow motion recording up to 120 fps in4.6K, 150 fps in 4K DCI and 300 fps in HD Blackmagic RAW
- Interchangeable lens mount with EF mount included as standard. Optional PL, B4 and F lens mounts available separately
- High quality 2, 4 and 6 stop neutral density (ND) filters with IR compensation designed to specifically match the colourimetry and colour science of Blackmagic URSA Mini Pro 4.6K G2
- Fully redundant controls including external controls which allow direct access to the most important camera settings such as external power switch, ND filter wheel, ISO, shutter, white balance, record button, audio gain controls, lens and transport control, high frame rate button and more
- Built in dual C-Fast 2.0 recorders and dual SD/UHS-II card recorders allow unlimited duration recording in high quality
- High speed USB-C expansion port for recording directly to an external SSD or flash disk
- Lightweight and durable magnesium alloy body
- LCD status display for quickly checking timecode, shutter and lens settings, battery, recording status, and audio levels
- Support for Blackmagic RAW files in Constant Bitrate 3:1, 5:1, 8:1 and 12:1 or Constant Quality Q0 and Q5 as well as ProRes 4444 XQ, ProRes 4444, ProRes 422 HQ, ProRes 422, ProRes 422 LT, ProRes 422 Proxy recording at 4.6K, 4K, Ultra HD and HD resolutions
- Supports recording of up to 300 frames per second in HD, 150 frames per second in 4K DCI, and 120 frames per second at full frame 4.6K
- Features all standard connections, including dual XLR mic/line audio inputs with phantom power, 12G-SDI output for monitoring with camera status graphic overlay and separate XLR 4 pin power output for viewfinder power, headphone jack, LANC remote control and standard 4 pin 12V DC power connection
- Built in high quality stereo microphones for recording sound
- 4 inch foldout touchscreen for on-set monitoring and menu settings
- Includes full copy of DaVinci Resolve software colour grading and editing software
Specifications
| Camera Features | |
| Effective Sensor Size | 25.34mm x 14.25mm (Super35) |
| Lens Mount | EF Mount (Interchangable with PL, B4 and F mount) |
| Lens Control | Electronic control via EF mount pins or 12-pin broadcast connector for compatible lenses |
| Dynamic Range | 15 Stops. |
| Shooting Resolutions | 4608 x 2592, 4608 x 1920 (4.6K 2.40:1), 4096 x 2304 (4K 16:9), 4096 x 2160 (4K DCI), 3840 x 2160 (Ultra HD), 3072 x 2560 (3K Anamorphic) |
| 2048 x 1152 (2K 16:9), 2048x1080 (2K DCI), 1920 x 1080 | |
| Frame Rates | Maximum sensor frame rate dependent on resolution and codec selected. Project frame rates of 23.98, 24, 25, 29.97, 30, 50, 59.94 60 fps supported. |
| High Speed Frame Rates | Blackmagic RAW 8:1: |
| 4.6K Full - Up to 120 fps | |
| UHD Windowed - Up to 150 fps | |
| HD Windowed - Up to 300 fps | |
| ProRes 422 HQ: | |
| 4.6K Full - Up to 80 fps | |
| UHD Windowed - Up to 120 fps | |
| HD Windowed - Up to 240 fps | |
| Built in ND Filters | Four position ND filter wheel with clear, 2-stop, 4- stop and 6-stop ND filters |
| Focus | Focus button turns on peaking, auto focus available using compatible lenses |
| Iris Control | Iris wheel and touchscreen slider for manual iris adjustment on electronically controllable lenses, iris button for instant auto iris |
| settings on compatible lenses so no pixel is clipped in film mode. Scene average auto exposure in video mode. | |
| Screen Dimensions | 4" |
| Screen Type | LCD capacitive touchscreen. |
| Metadata Support | Automatically populated lens data from electronic EF, B4 and i/Technology compatible PL lenses. |
| Automatic recording of camera settings and slate data such as project, scene number, take and special notes. | |
| Controls | Touchscreen menus on 4” screen. Push buttons for other controls. 2 assignable shortcut keys. |
| Timecode Clock | Highly accurate timecode clock. Less than 1 frame drift every 8 hours. |
| Connections | |
| Total Video Input | 1 x SDI |
| Total Video Output | 1 x SDI, 1 x SDI Monitoring. |
| SDI Rates | 1.5G, 3G, 6G, 12G. |
| Analogue & AES Audio Input | 2 x XLR analog switchable between mic, line and AES audio. Phantom power support. |
| Analogue Audio Output | 1 x 3.5mm headphone jack, supports iPhone microphone for talkback. |
| Reference Input | Tri-Sync/Black Burst/Timecode. |
| Remote Control | 2 x 2.5mm LANC input for Rec Start/Stop, plus Iris and Focus control using compatible lenses. |
| Computer Interface | USB Type-C 3.1 Gen 1 for external drive recording and software updates. |
| Audio | |
| Microphone | Integrated stereo microphone. |
| Built-in Speaker | 1 x mono speaker. |
| Standards | |
| SD Video Standards | None. |
| HD Video Standards | 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60, 1080i50, 1080i59.94, 1080i60 |
| Ultra HD Video Standards | 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60 |
| SDI Compliance | SMPTE 292M, SMPTE 424 Level B, SMPTE 2081-1, SMPTE 2082-1 |
| SDI Audio Sampling | 48 kHz and 24 bit |
| Media | 2x CFast 2.0 for 4.6K RAW and ProRes recording. 2x SD UHS-II card slots for HD and Ultra HD recording. 1x USB-C 3.1 Gen 1 |
| Media Format | Can format discs to ExFAT (Windows/Mac) or HFS+ (Mac) file systems. |
| Supported Codecs | |
| Codecs | Blackmagic RAW Constant Bitrate 5:1,Blackmagic RAW Constant Bitrate 8:1,Blackmagic RAW Constant Bitrate 12:1,Blackmagic RAW Constant Quality Q0,Blackmagic RAW Constant Quality Q5, |
| Apple ProRes XQ QuickTime, Apple ProRes 444 QuickTime,Apple ProRes 422 HQ QuickTime, Apple ProRes 422 QuickTime,Apple ProRes 422 HQ QuickTime, Apple ProRes 422 LT QuickTime,Apple ProRes 422 Proxy QuickTime. | |
| Control | |
| External Control | SDI Control Protocol, iPad Control, Bluetooth control, 2x 2.5mm LANC |
| Colour Corrector | DaVinci YRGB. |
| Talkback and Tally | |
| Live Tally Indicator | Tally on LCD, URSA Viewfinder and URSA Studio Viewfinder. |
| Talkback | SDI Channels 15 and 16 and iPhone headset |
| Storage Features | |
| Storage Type | 2 x CFast 2.0 |
| 2 x SD UHS-II cards | |
| 1x High Speed USB-C expansion port | |
| Storage Rates | 4608 x 2592 |
| Blackmagic RAW 5:1 - 110 MB/s | |
| Blackmagic RAW 8:1 - 68 MB/s | |
| Blackmagic RAW 12:1 - 46 MB/s | |
| Blackmagic RAW Q0 - 110 to 274 MB/s * | |
| Blackmagic RAW Q5 - 27 to 78 MB/s ** | |
| Apple ProRes XQ - 360 MB/s | |
| Apple ProRes 444 - 238 MB/s | |
| Apple ProRes HQ - 158 MB/s | |
| Apple ProRes 422 - 106 MB/s | |
| Apple ProRes LT - 73.5 MB/s | |
| Apple ProRes Proxy - 32.3 MB/s | |
| 3840 x 2160 | |
| Blackmagic RAW 3:1 - 127 MB/s | |
| Blackmagic RAW 5:1 - 76 MB/s | |
| Blackmagic RAW 8:1 - 48 MB/s | |
| Blackmagic RAW 12:1 - 32 MB/s | |
| Blackmagic RAW Q0 - 76 to 191 MB/s * | |
| Blackmagic RAW Q5 - 19 to 55 MB/s ** | |
| Apple ProRes XQ - 250 MB/s | |
| Apple ProRes 444 - 165 MB/s | |
| Apple ProRes HQ - 110 MB/s | |
| Apple ProRes 422 - 73.6 MB/s | |
| Apple ProRes LT - 51 MB/s | |
| Apple ProRes Proxy - 22.4 MB/s | |
| 1920 x 1080 | |
| Blackmagic RAW 3:1 - 33 MB/s | |
| Blackmagic RAW 5:1 - 20 MB/s | |
| Blackmagic RAW 8:1 - 12 MB/s | |
| Blackmagic RAW 12:1 - 8 MB/s | |
| Blackmagic RAW Q0 - 20 to 49 MB/s * | |
| Blackmagic RAW Q5 - 5 to 14 MB/s ** | |
| Apple ProRes XQ - 62.5 MB/s | |
| Apple ProRes 444 - 41.25 MB/s | |
| Apple ProRes HQ - 27.5 MB/s | |
| Apple ProRes 422 - 18.4 MB/s | |
| Apple ProRes LT - 12.75 MB/s | |
| Apple ProRes Proxy - 5.6 MB/s | |
| Recording Formats | Blackmagic RAW Q0, Q5, 3:1, 5:1, 8:1 and 12:1 at 4608 x 2592, 4608 x 1920, 4096 x 2304, 4096 x 2160, 3840 x 2160, 3072 x 2560, 2048 x 1152, 2048 x 1080 and 1920 x 1080 with film, extended video or video dynamic range. |
| ProRes at 4608 x 2592, 4608 x 1920, 4096 x 2304, 4096 x 2160, 3840 x 2160, 3072 x 2560, 2048 x 1152, 2048 x 1080 and 1920 x 1080 with film, extended video or video dynamic range. | |
| Software | |
| Software Included | URSA Mini Operating System. |
| DaVinci Resolve Studio for Mac and Windows including activation key | |
| Blackmagic Camera Setup. | |
| Blackmagic RAW Player | |
| Blackmagic RAW QuickLook Plugin | |
| Blackmagic RAW SDK | |
| Operating Systems | MAC OS 10.13 High Sierra, Mac OS 10.14 Mojave or later |
| Windows 8.1 or Windows 10 | |
| Power Requirements | |
| Power Supply | 1 x External 12V power supply. 12-pin Molex connector on rear battery plate. |
| External Power Input | 1 x 4-pin XLR port for external power or battery use. |
| 1 x 12-pin molex connector on rear battery plate. | |
| Custom V-mount battery plate with D-tap +12V regulated output from camera. | |
| Power | Rear camera mount compatible with industry standard V-mount or gold mount battery plates. |
| Physical Specifications | |
| Dimensions | 202 x 209 x 146.8mm |
| Weight | 2.31 kg |
| Environmental Specifications | |
| Operating Temperature | 0°to 40°C (32° to 104°F) |
| Storage Temperature | -20°to 45°C (-4° to 113°F) |
| Relative Humidity | 0% to 90% non-condensing |
