Introducing the Marshall HD PTZ Camera - a game changer for corporate meetings and live events. With its 5x zoom lens and multiple outputs, elevate your conferencing game to new heights. Its ease of setup and compatibility with popular services make it a versatile must-have.
Features
- 1/2.8" 2.07MP HD CMOS Sensor
- 5x Optical Zoom, 10x Digital Zoom
- Up to 1920 x 1080p60 Video Output
- USB 3.1 Type-C, HDMI, LAN Output
- 255 Preset Positions, 10 by IR Remote
- ±135° Pan, ±30° Tilt Ranges
- IP/IR Remote/RS-232 Control
- Zoom Conference Software Certified
Specifications
| Image Sensor |
1/2.8"-Type CMOS |
| Sensor Resolution |
Effective: 2.07 Megapixel |
| Shutter Speed |
1/10000 to 1/25 Second |
| Optical Zoom Ratio |
5x |
| External Recording Modes |
HDMI/RJ45/USB |
| Broadcast Output |
NTSC |
| IP Streaming |
H.264, H.265, RTMP, RTSP
1920 x 1080 at 25p, 29.97p, 50p, 59.94p
1280 x 720 at 25p, 29.97p, 50p, 59.94p
640 x 480 at 25p, 29.97p, 50p, 59.94p |
| Supported Control Protocols |
IP
IR
Pelco-D
Pelco-P
RS-232
VISCA |
| PoE Support |
PoE 802.3af |
| Power Consumption |
Power Supply: 110 to 220 VAC at 1.5 A (12 W) |
| Mounting |
1x 1/4"-20 Female |
| Exposure Control |
|
| Presets |
One Push, Manual, Auto |
| Range |
2400 to 7100K |
| Lens Focal Length |
3.1 to 15.5mm |
| Field of View |
84 to 20° |
| Maximum Aperture |
f/1.8 to 11 |
| Pan/Tilt |
Pan: 270° (-135 to 135°) at 0.1 to 60°/s
Tilt: 60° (-30 to 30°) at 0.1 to 30°/s |
| Interface |
|
| - Video I/O |
1x HDMI 1.0 Output
1x USB-C 3.0 / 3.1/3.2 Gen 1 Output |
| -Audio I/O |
1x 1/8" / 3.5 mm TRS Stereo Microphone Input |
| -Other I/O |
1x RJ45 (RS-232) Input
1x RJ45 (LAN) Control Input (Shared with Video Output)
1x USB-C (USB 3.2 / 3.1 Gen 1) Video Input |
| Built-In Microphone |
No |
| Built-In Speaker |
No |
| Impact Resistance |
No |
| Environmental Resistance |
No |
| Security Lock Support |
- |
| Weight |
1.29 Kg |
What's In The Box
- Marshall Electronics CV605-U3 Compact PTZ USB/HDMI Camera (White)
- IR Remote Control
- Power Adapter
- USB Type-C Cable
- Limited 1-Year Manufacturer Warranty
