The Marshall 3.2mm F2.0 CS Mount Prime Lens is engineered for 12MP cameras with a 1/1.7" sensor, offering exceptional clarity and precision. Its 3.2mm focal length provides a wide 131° horizontal field of view, ideal for capturing expansive scenes with remarkable detail. Featuring IR correction and a fixed iris, this lens ensures consistent image quality in varied lighting conditions, making it a refined choice for high-resolution 4K/UHD imaging applications.
Features
- Compatible with 12MP Cameras
- CS Mount
- 3.2mm Focal Length
- Compatible with 1/1.7" Sensors
- 131° Horizontal Field of View
- IR Corrected
- Fixed Iris Operation
Specifications
| Lens Mount |
CS |
| Sensor Compatibility |
1/1.7", 1/1.8", 1/2.3" |
| Focal Length |
3.2mm |
| Back Focal Length |
6mm |
| Maximum Aperture |
f/2 |
| Angle of View |
1/1.7"-Type Sensor |
|
Diagonal: 160° |
|
Horizontal: 131° |
|
Vertical: 99° |
|
1/1.8"-Type Sensor |
|
Diagonal: 153.6° |
|
Horizontal: 129° |
|
Vertical: 88° |
|
1/2.3"-Type Sensor |
|
Diagonal: 136° |
|
Horizontal: 113.5° |
|
Vertical: 83° |
| Minimum Focus Distance |
From Front of Lens: 0.3 m |
| Focus Type |
Fixed Focus |
| Iris Type |
Fixed |
| IR Corrected |
Yes |
| Weight |
53 g |
What's in the box
- Marshall Electronics CS-3.2-12MP CS-Mount 3.2mm Fixed Focal Lens
- Limited 1-Year Manufacturer Warranty
