The Marshall 3.8-16mm F1.4 CS-Mount lens is engineered for 8MP 4K/UHD cameras with a 1/1.7" sensor, delivering exceptional image clarity through advanced IR-corrected glass elements. Its versatile 3.8-16mm focal range offers a diagonal field of view from approximately 112° to 30°, allowing precise framing. Featuring a DC auto iris for optimal exposure and manual focus and zoom with lock screws, this lens ensures refined control and consistent performance in demanding surveillance or imaging applications.
Features
- Compatible with 8MP Cameras

- CS Mount, Improved Glass Elements

- Compatible with 1/1.7" Sensors

- 3.8-16mm Focal Length

- 148 to 35.8° Diagonal Field of View

- IR Corrected

- DC Auto Iris

- Manual Focus and Zoom with Lock Screws

Specifications
| Lens Mount |
CS |
| Sensor Compatibility     |
1/1.7", 1/1.8", 1/1.9" (8 MP) |
| Focal Length     |
3.8 to 16mm |
| Back Focal Length     |
7.9mm |
| Maximum Aperture     |
f/1.4 |
| Angle of View     |
1/1.7"-Type Sensor |
 |
Diagonal: 148 to 35.8° |
 |
Horizontal: 112.3 to 29.2° |
 |
Vertical: 56.8 to 15.5° |
 |
1/1.8"-Type Sensor |
 |
Diagonal: 140.7 to 34.7° |
 |
Horizontal: 106 to 27.8° |
 |
Vertical: 76.4 to 20.9° |
 |
1/1.9"-Type Sensor |
 |
Diagonal: 131.6 to 33° |
 |
Horizontal: 107.8 to 28.2° |
 |
Vertical: 64.4 to 17.8° |
| Minimum Focus Distance     |
20.12 cm |
| Focus Type     |
Manual Focus |
| Iris Type     |
DC Auto |
| IR Corrected     |
Yes |
| Weight |
256 g |

What's in the box
- Marshall Electronics CS-3816-8MP-V2 8MP CS-Mount 3.8-16mm Varifocal Lens

- Limited 2-Year Manufacturer Warranty
