Science Image 2-Channel SDI/HDMI In/Out Converter delivers high-bandwidth NDI encoding and decoding with 12G-SDI and HDMI 4K60 support in a compact 1 RU chassis. Designed for professional studios, it efficiently manages multiple NDI sources and destinations while ensuring pristine video and audio transmission over fiber connections. This versatile device also functions as a display management system for digital signage, combining advanced connectivity with reliable performance for seamless integration in demanding broadcast environments.
Features
- 4K SDI/HDMI/Full NDI Converter
- Video Formats up to 4K60
- HDMI, 12G-SDI & RJ45 NDI Connectivity
- Up/Down/Cross Conversion of 27 Formats
- Dedicated LED Screen for Each Channel
- VISCA & PELCO-P/D Protocol Support
- 1 RU Short-Depth Chassis
Specifications
| Inputs / Outputs |
|
| Video Inputs |
Input |
|
2x BNC (12G-SDI) Female |
|
2x HDMI 2.0 Female |
|
Output |
|
2x BNC (12G-SDI) Female |
|
2x HDMI 2.0 Female |
|
Input/Output |
|
2x opticalCON |
| Audio Inputs |
Input |
|
2x 1/8" / 3.5 mm TRS Stereo Analog Female (Loop Output) |
|
2x 1/8" / 3.5 mm TRRS Headphone/Microphone Stereo Analog Female |
| Video Outputs |
BNC Input/Output |
|
3840 x 2160 at 23.98/24/25/29.97/30/50/59.94/60 fps |
|
2560 x 1440 at 23.98/24/25 fps |
|
1920 x 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps |
|
1920 x 1080PsF at 23.98/24/25/29.97/30 fps |
|
1920 x 1080i at 50/59.94/60 fps |
|
1280 x 720 at 50/59.94/60 fps |
|
HDMI Input/Output |
|
3840 x 2160 at 23.98/24/25/29.97/30/50/59.94/60 fps |
|
2560 x 1440 at 23.98/24/25 fps |
|
1920 x 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps |
|
1920 x 1080PsF at 23.98/24/25/29.97/30 fps |
|
1920 x 1080i at 50/59.94/60 fps |
|
1280 x 720 at 50/59.94/60 fps |
|
Fiber Input/Output |
|
3840 x 2160 at 23.98/24/25/29.97/30/50/59.94/60 fps |
|
2560 x 1440 at 23.98/24/25 fps |
|
1920 x 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps |
|
1920 x 1080PsF at 23.98/24/25/29.97/30 fps |
|
1920 x 1080i at 50/59.94/60 fps |
|
1280 x 720 at 50/59.94/60 fps |
| Other I/O |
Input/Output |
|
2x RJ45 (LAN) |
| Expansion Slots |
No |
| Input Video Format |
Analog, Unspecified Digital Signal |
| Output Video Format |
Analog, Unspecified Digital Signal |
| Embedded Audio |
Fiber/HDMI/SDI |
| Video Standard Compliance |
SMPTE: 259M/292M/296M/372M/424M/425M/ST-2081-1/ST-2082-1/ST-2082-10 |
| Power |
|
| Power I/O |
1x IEC C13 Input |
| PoE Support |
- |
| Power Consumption |
- |
| Environmental |
- |
| Operating Temperature |
- |
| Storage Temperature |
- |
| Operating Humidity |
- |
| General |
- |
| Dimensions |
50.8 x 30.5 x 15.2 cm |
| Weight |
3.6 kg |
What's in the box
- SCIENCE IMAGE Studio Edge 2-Channel Rackmount Bidirectional 4K SDI/HDMI/Full NDI Converter (1 RU)
- Limited 3-Year Manufacturer Warranty
