The Panasonic AW-HE20KEJ Full-HD PTZ Camera delivers exceptional 1080p video quality with versatile connectivity options including 3G-SDI, HDMI, USB, and IP streaming. Featuring a 1/2.8" MOS sensor and a 12x optical zoom lens, it captures detailed images from a distance, ideal for conference rooms, houses of worship, and educational settings. Remote control via web browser enhances monitoring flexibility, while integrated audio input and serial control support comprehensive AV setups. This sophisticated camera combines precision, connectivity, and ease of use for professional-grade video production and surveillance.
Features
- 1/2.8" Full HD MOS Sensor
- Up to 1080p 3G-SDI/HDMI/IP/USB Output
- 12x Optical Zoom
- ±170° Pan, -30 to 90° Tilt
- LAN, UVC, and Serial Control
- Mic/Line Stereo Audio Input
- PoE+ Compatible
Specifications
| Image Sensor |
1/2.8"-Type MOS |
| Sensor Resolution |
- |
| Shutter Speed |
1/16000 to 1 Second |
| Optical Zoom Ratio |
12x |
| External Recording Modes |
- |
| Broadcast Output |
NTSC/PAL |
| IP Streaming |
H.264, H.265, MJPEG, RTP, RTSP, TCP, UDP |
|
1920 x 1080 at 5.00p, 10p, 14.99p, 25p, 29.97p, 50p, 59.94p |
|
1280 x 720 at 5.00p, 10p, 14.99p, 25p, 29.97p, 50p, 59.94p |
|
640 x 360 at 5.00p, 10p, 14.99p, 25p, 29.97p, 50p, 59.94p |
| Supported Control Protocols |
IP |
|
RS-232 |
|
RS-422 |
| PoE Support |
PoE+ 802.3at |
| Power Consumption |
Device: 10.8 to 13.2 VDC at 1.3 A |
|
PoE: 42.5 to 57 VDC at 0.4 |
| Mounting |
- |
| Exposure Control |
|
| Presets |
ATW, AWB |
| Range |
3200 to 5600K |
| Lens Focal Length |
3.9 to 46.8mm |
| Field of View |
Horizontal: 71 to 6° |
|
Vertical: 43 to 3° |
|
Diagonal: 79 to 7° |
| Maximum Aperture |
f/1.6 to 2.8 |
| Pan/Tilt |
- |
| Interface |
|
| - Video I/O |
1 x BNC (3G-SDI) Output |
|
1 x HDMI Output |
|
1 x USB-B 2.0 Output |
|
1 x RJ45 (NDI) Output |
| -Audio I/O |
3.5 mm TRS Stereo Mic/Line Input |
| -Other I/O |
1x RJ45 (LAN) Input |
|
1x Mini-DIN 8-Pin (RS-232) Input |
|
1x Mini-DIN 8-Pin (RS-232) Output |
|
1x RJ45 (RS-422) Output |
| Built-In Microphone |
- |
| Built-In Speaker |
No |
| Impact Resistance |
- |
| Environmental Resistance |
- |
| Security Lock Support |
- |
| Weight |
1.9 kg (Body Only) |
What's in the box
- Panasonic AW-HE20 3G-SDI/HDMI/IP/USB PTZ Camera with 12x Optical Zoom (White)
- Power Adapter
- Limited 1-Year Manufacturer Warranty
