Elevate your presentations with the Panasonic AW-UE30KEJ, a sophisticated 4K30 HDMI PTZ camera delivering stunning UHD 4K video via HDMI 1.4. Its large 1/2.5" MOS sensor and 20x optical zoom with a wide 74.1° field of view capture every detail with clarity. Designed for seamless integration, it supports IP live streaming up to 1080p and functions as a webcam through its USB Type-C port. PoE+ compatibility enables streamlined single-cable operation, making it ideal for conference rooms and classrooms seeking professional-grade video quality.
Features
- 1/2.5" 4K MOS Sensor, up to UHD 4K30
- HDMI 1.4, USB, and IP Video Output
- 20x Optical, 23x UHD, and 30x HD Zoom
- Built-In Auto Tracking
- Wide 74.1° Horizontal Angle of View
- Remote Controller and Web GUI Options
- Stream 1080p to Platforms via H.264/265
- Stereo Mini-Jack Audio Mic/Line Input
Specifications
| Image Sensor |
1/2.5"-Type MOS |
| Sensor Resolution |
Effective: 8.49 Megapixel |
| Shutter Speed |
1/10000 to 1/25 Second |
| Optical Zoom Ratio |
20x |
| External Recording Modes |
- |
| Broadcast Output |
NTSC |
| IP Streaming |
H.264/H.265 via RTMP/RTMPS/RTP/RTSP/SRT/TCP/UDP |
|
1980 x 1080 at 60p |
| Supported Control Protocols |
IP |
|
NDI|HX2 |
|
RS-422 |
| PoE Support |
PoE+ 802.3at |
| Power Consumption |
- |
| Mounting |
1x M4 Female |
| Exposure Control |
|
| Presets |
ATW, AWB |
| Range |
2000 to 15,000K |
| Lens Focal Length |
4.12 to 82.4mm (35mm Equivalent: 25 to 500mm) |
| Field of View |
Horizontal: 74.1 to 3.3° |
|
Vertical: 46 to 1.9° |
|
Diagonal: 81.8 to 3.8° |
| Maximum Aperture |
f/1.8 to 3.9 |
| Pan/Tilt |
Pan: 350° (-175 to 175°) |
|
Tilt: 120° (-30 to 90°) |
| Interface |
|
| - Video I/O |
1 x HDMI 1.4 Output |
|
1 x USB-C 2.0 Output |
|
1 x RJ45 (NDI) Output |
| -Audio I/O |
1x 1/8" / 3.5 mm TRS Stereo Mic/Line Input |
| -Other I/O |
1x RJ45 (RS-422) Control |
|
1x RJ45 (LAN) Control |
| Built-In Microphone |
No |
| Built-In Speaker |
No |
| Impact Resistance |
- |
| Environmental Resistance |
- |
| Security Lock Support |
- |
| Weight |
1.8 kg (Body Only) |
What's in the box
- Panasonic UE30 4K30 HDMI PTZ Camera with 20x Optical Zoom (Black)
- Power Supply
- Limited 1-Year Manufacturer Warranty
