The Panasonic AW-UE4KG Compact 4K PTZ Camera delivers ultra-high-definition 4K30 video with a wide 111° field of view, ideal for professional streaming and recording. Featuring built-in stereo microphones with mute and ACL functions, it captures clear LPCM or AAC-LC audio at 48 kHz, 16-bit quality. Its versatile connectivity includes USB and PoE for seamless single-cable power and data transfer, supporting cable runs up to 328 feet. With HDMI output and up to 4x zoom, this camera excels in lecture capture, video conferencing, and live e-Sports streaming, combining compact design with advanced performance.
Features
- Single-Cable USB/LAN (PoE) Connectivity
- UHD 4K30 and RTMP/RTMPS Direct Streaming
- 111° FOV for Large Spaces, eSports
- Stereo Mic with Mute and ACL Functions
- LPCM/AAC-LC 48 kHz, 16-Bit Audio Capture
- ePTZ (4x Zoom)
- HDMI Video Output
- AW-RP60GJ & AW-RM50G Controller Support
Specifications
| Image Sensor |
1/2.5"-Type MOS |
| Sensor Resolution |
- |
| Shutter Speed |
1/160000 to 1 Second |
| Optical Zoom Ratio |
- |
| External Recording Modes |
- |
| Broadcast Output |
NTSC |
| IP Streaming |
H.264/H.265/MJPEG via RTMP/RTMPS/RTP/RTSP/TCP/UDP |
|
3840 x 2160 at 5.00p, 10p, 14.99p, 25p, 29.97p |
|
640 x 360 to 1920 x 1080 at 5.00p, 10p, 14.99p, 25p, 29.97p, 50p, 59.94p |
| Supported Control Protocols |
IP |
|
IR |
| PoE Support |
PoE 802.3af |
| Power Consumption |
Power Supply: 1 A |
|
PoE: 0.2 A |
| Mounting |
1x 1/4"-20 Female for Bracket/Tripod |
| Exposure Control |
|
| Presets |
100 |
| Range |
3200 to 5600K |
| Lens Focal Length |
2.2mm (35mm Equivalent: 13.4mm) |
| Field of View |
Horizontal: 111° |
|
Vertical: 75° |
|
Diagonal: 120° |
| Maximum Aperture |
f/2.4 |
| Pan/Tilt |
Pan: 220° |
|
Tilt: 50° |
| Interface |
|
| - Video I/O |
1 x HDMI (Unspecified Signal) Output |
| -Audio I/O |
- |
| -Other I/O |
1x RJ45 (LAN) Control Input (Shared with Power Input, Video Output) |
|
1x USB-C (USB 3.0) Control Input (Shared with Video Output) |
| Built-In Microphone |
Stereo |
| Built-In Speaker |
- |
| Impact Resistance |
- |
| Environmental Resistance |
- |
| Security Lock Support |
- |
| Weight |
0.5 kg (Body Only) |
What's in the box
- Panasonic AW-UE4KG Compact 4K PTZ Camera with IP Streaming (Black)
- USB Cable
- Drop-Prevention Wire
- Mount Kit
- L-Mount Kit
- 1/4"-20 Screw
- 4 x M4 Screw (10mm)
- 4 x M4 Screw (5mm)
- Limited 1-Year Manufacturer Warranty
